100MHz to 40GHz Digital Attenuator

PMI Model DTA-100M40G-30-CD-1 is a 5-Bit programmable 30dB PIN diode attenuator with a step resolution of 1.0dB over the frequency range of 100MHz to 40GHz. This model operates on a single +15VDC supply and draws only 40mA of current.  Very high levels of attenuation accuracy of 0.6dB is achieved.  This attenuator provides ultra-fast switching speeds of 300nsec and has an operating input power rating of +20dBm.  This model is supplied in a small, light-weight housing measuring 2.0 x 1.8 x 0.5 inches.

World's Smallest, Lowest Power Consumption, CW Immune ERDLVA

2.0 to 18.0GHz

Frequency Flatness: ± 2.0dB max.

Logging Range of -60 to +4dBm

TSS: -64dBm min.

Log Slope: 77mV/dB

Fast Rise Time of 20nsec

CW Immunity: TSS to -40dBm

Total Power of < 3.9 Watts

Small Size: 2.04" x 1.67" x 0.472"

Hermetically Sealed

Designed for UAV and Airborne applications.

Ultra small, light and powerful ERDLVA.

Best used when limited DC power is available.

1-18GHz, 10 Watt Switch with 40nsec Speeds

PMI Model No.P2T-1G18G-10-R-528-SFF-HIP10W is a single pole, two throw, reflective switch capable of operating with an input power of 10W CW over the 1.0 to 18.0GHz frequency range.  This model features high input power handling capability while offering very fast switching speeds of 40nsec.  This switch is compact in size and weight and only consumes 2.5mA of positive and 2.5mA of negative DC current making it suitable for a wide range of applications.

Ultra-Fast, High Power, Solid-State, SPDT Switch

2.2 to 2.5GHz

(Up to 40GHz Available)

Low Loss

100W CW Hot Switching Capable

High Isolation

Ultra-Fast Switching Speed

Rugged Hermetic Package

Single Line TTL Control

700-1300MHz SDLVA

Frequency: 700-1300MHz

Logging Range: -70 to +5dBm

Log Linearity: ±1.2dB

Limited IF Output: +5dBm typ.

Rise Time: 9nsec

Fall Time: 25nsec

Log Slope: 40mV/dB

Video Load: 50 Ohms

Size: 3.75" x 1.5" x 0.5"

6.0 to 18.0GHz, Ultra-Fast, SDLVA

PMI model SDLVA-6G18G-CD-1 Successive Detection Log Video Amplifiers (SDLVA) offers 75dB Dynamic Range over the frequency range of 6.0 to 18.0GHz.  This model offers an ultra-fast rise time of 10nsec maximum and a recovery time of less than 60nsec.  The unit is temperature compensated such that log linearity over temperature remains less than +/-2.5dB over the full operating temperature range of -40 to +85C.  This model is supplied in a compact housing measuring only 3.2" x 1.8" x 0.4".  [Optional frequency ranges covering 100MHz to 26.5GHz are available.]

12.8GHz Dielectric Resonator Oscillator

PMI Model No. PIA-12D8G-CD-1 is a Phase Locked, Dielectric Resonator Oscillator with Internal Reference having an output frequency of 12.8GHz. This model provides a minimum output of +13dBm with all spurs held to -80dBc and harmonics held to -25dBc. The frequency stability is ±3 ppm with an internal reference of 100MHz. The phase noise is as follows: -34dBc/Hz at 1Hz, -65dBc/Hz at 10Hz, -85dBc at 100Hz, -108dBc/Hz at 1kHz, -115dBc/Hz at 10kHz, -120dBc/Hz at 100kHz, and -140dBc/Hz at 1MHz offsets. The oscillator requires +15VDC and 300mA. There is a built in alarm which outputs a TTL signal when phase locked. The unit measures 2.25" x 2.25" x 0.62". Other frequency ranges are available.

2.0 to 18.0GHz, Ultra-Fast, CW Immune, ERDLVA

PMI model SDLVA-218-71-70MV is a CW Immune, Extended Range Detection Log Video Amplifiers (ERDLVA) which offers 71dB Dynamic Range over the frequency range of 2.0 to 18.0GHz.  This model offers a fast rise time of 35nsec maximum and a recovery time of less than 350nsec.  The unit is temperature compensated such that log linearity over temperature remains less than +/-1.5dB over the full operating temperature range of -20 to +85C.  This model is supplied in a compact housing measuring only 3.5" x 2.5" x 0.5".  [Optional frequency ranges covering 100MHz to 26.5GHz are available.]

PMI Model No. P7T-0R8G18G-60-T-SFF-SMC is a high speed, single pole, seven throw, absorptive switch capable of switching within 75nsec. The frequency range is 0.8 to 18.0GHz and has over 60dB of isolation with insertion loss of 4.3dB maximum. This switch operates on +5V, 280mA and -5V, 30mA typically and has an operating input power rating of +20dBm CW.
